Technical Features
::
Individual control of 6 DMX 512 projectors
(scanners/colorchangers/etc.).
::
6 DMX channels for each projector (36 total channels).
::
6 programmed sequences with 12 scenes each one
(72 total scenes).
::
DMX 512/1990 standard output (5-pin "XLR" connector).
::
Mirror's movement (ch. 5 & 6)
controlled by an high quality Joystick.
::
SPEED adjustment to change the speed
of the mirror's movement.
::
SEL and AUTO functions execute one or more programs.
::
RND function performs all the scenes at random,
creating always different movements.
::
PROG + MAN function controls manually one
or more projectors, while the others run a program.
::
BLK function blackouts all the projectors.
::
Dimensions (L-H-W mm): 230 x 175 x 40.
::
Net weight: 2 Kg.
|
